/ Non-contact controls Foot or knee-operated

TEMPOGENOU MIXFOOT/MONOFOOT
Knee-operated time flow basin valve Foot-operated basin mixer with instant shut-off

• Time flow ~7 seconds. • Instant automatic shut-off.
• Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm. • Pedal can be raised to clean the floor.
• Reinforced control lever. • Adjustable pedal height.
• Solid brass escutcheon with reinforced fixing via 4 stainless steel • Fixed by 4 screws.
screws on the in-line model� • Filters.
• Cold or mixed water supply� • Pre-set mixing can be adjusted on the MIXFOOT mixer version:
• Chrome-plated solid brass body, M½”. half-open for cold water and fully open for mixed water
• 30-year warranty� (pedal touching the floor).
• Available for floor or wall-mounting.
• 30-year warranty.

30
1/2" 1/2"
Ø 80
280
1/2"
435
735400 739100

Ø 15
37
Ø 70 Ø 14
Ø 15 280
440
73544715 736001

35
1/2"
Ø 50
440 1/2"
734100

MIXFOOT mixer
TEMPOGENOU valve Floor-mounted, M½" 739100
Straight for in-line inlet, stud nut 735000 Wall-mounted, M½" 739102
Straight for in-line inlet, M½” 735400 MONOFOOT valve
Straight for in-line inlet Ø 15mm compression fittings 73544715 Floor-mounted, stud nut Ø 14mm 736001
Angled for recessed inlet, M½” 734100 Floor-mounted, M½" 736101
We recommend installing a TMV (see page 78) We recommend installing a TMV (see page 78) with the MONOFOOT valve
Option: spouts (see opposite) Option: spouts (see opposite)

54 Non-contact controls
