Non-contact controls Spouts /

Fixed spout Fixed L-shaped spout Fixed spout
Wall-mounted/Cross wall Wall-mounted For thin wall

• Spout Ø 32mm, M½"� • Tubular spout Ø 18mm, M½"� • Spout L� 75mm, M½"�
• Chrome-plated brass� • L� 120mm� • For thin walls�
• Scale-resistant flow straightener regulated • Chrome-plated brass� • Threaded rod can be cut to size�
at 3 lpm� • Flow straightener� • Streamlined, ligature-resistant design�
• 30-year warranty� • 30-year warranty� • Chrome-plated brass�
• Star-shaped, scale-resistant flow straightener�
Ø 32 Ø 60 Ø 21 1/2" • 30-year warranty�

120 165 max
10 max
1/2"
Ø 48 Ø 21 1/2"
947151
60
120
Cross wall spout with escutcheon 75 30 max
L. 120mm 947151
941922 942040
L. 170mm 947157
Wall-mtd spout, no escutcheon (recessed inlet) NON-CONTACT CONTROLS
L. 110mm 947120 Wall-mounted fixed L-shaped spout
L. 160mm 947170 Fixed spout for thin walls
Star-shaped flow straightener 941120
Wall-mtd spout with escutcheon (recessed inlet) Flow straightener regulated at 3 lpm For walls ≤ 30mm 942040
L. 120mm 947135 for panels ≤ 10mm 941922 Back-nut with 3 screws 826315
Tubular spout Fixed or swivelling spout Hygienic flow straightener
Deck-mounted Deck-mounted

• Tubular spout on M½" base� • Spout M½". • Flow straightener with no grid reduces bacterial
• Chrome-plated brass� • Fixed via back-nut on models 967152 & 967202, development (no water or dirt retention)�
• Spout with smooth interior reinforced fixing via 3 stainless steel screws • Models 922024�2P & 922022�2P:
(reduces bacterial development)� on model 981142� scale-resistant flow straightener pre-set
• Scale-resistant flow straightener� • Chrome-plated brass� at 3 lpm (DELABIE patented)�
• 30-year warranty� • Scale-resistant flow straightener regulated Flow rate can be adjusted from 1.4 - 6 lpm
at 3 lpm� at 3 bar (depends on mixer/tap model)
• 30-year warranty� from the outside using a 2�5mm Allen key�
• 30-year warranty�
150
22/100
170 24×100
140
150 120 120 15 17
1/2"
1/2" 150 922024.2P 921022.50P
25 max 15 max 1/2" 30 max 1/2" 30 max Scale-resistant flow straightener
1306T1 204001 140 M24x100 (2 per pack) 922024.2P
967152 981142
Swivelling tubular spout Ø 22mm F22x100 (2 per pack) 922022.2P
L� 150mm H� 140mm, 3 lpm 1306T1 Swivelling swan neck spout F22x100 (2 per pack) 921022.2P
L� 200mm H� 260mm, 3 lpm 1306T2 L� 150mm H� 120mm 967152 F22x100 (50 per pack) 921022.50P
L� 300mm H� 260mm 1306T3 L� 200mm H� 200mm 967202 M24x100 (2 per pack) 921024.2P
Fixed tubular spout Ø 16mm 204001 Fixed, cast spout 981142 M24x100 (50 per pack) 921024.50P

Non-contact controls 55
