Page 76 - professional-catering

/ Soap dispensers

Liquid soap dispenser Cross wall soap dispenser
Deck-mounted Wall-mounted for cross wall installation

• Model to be fitted on the basin� • Vandal-resistant model for cross wall installation (up to 190mm).
• Vandal-resistant model. • Body and push-button in polished 304 stainless steel.
• Body and push-button in polished 304 stainless steel. • Non-drip system (waterproof)
• Non-drip system (waterproof)� • For remote tanks (tank not supplied) with 1.2m flexible hose.
• Discreet locking mechanism: unlocks without special tools • 30-year warranty.
and relocks automatically�
• Models with tank: compatible with hydroalcoholic gel; fill from the top
(by unlocking the mechanism) or from below the counter (by unclipping
the tank)�
• 30-year warranty�

95
95
71 Ø 49 60 71 Ø 49 60
1/2" 1/2" 190 max 71
27
40 max 40 max 1,2 m Ø 9 1/2" Ø 49 64

241 1200 max

Ø 84

729564 729164 729170

Deck-mounted liquid soap dispenser - bright polished
With 1 litre tank 729064
With 0.5l tank 729564
With 1.2m flexible hose for remote tanks (not included) 729164
Deck-mounted liquid soap dispenser - polished satin
With 1 litre tank 729064S Cross wall soap dispenser, for remote tanks
With 0.5l tank 729564S Bright polished 729170
With 1.2m flexible hose for remote tanks (not included) 729164S Polished satin 729170S

74 Additional fittings
