P. 80
/ Group thermostatic mixing valves and pre-mixer
PREMIX NANO PREMIX COMPACT Pre-mixer Compact
Thermostatic mixing valve Thermostatic mixing valve
• For installation upstream of the tap� • For installation upstream of the tap� • For installation beneath a single basin.
• For 1 - 2 taps. • For 1 - 11 sanitary points-of-use • Nickel-plated body MF½".
• Anti-scalding failsafe: immediate shut-off (depending on the flow rate)� • Controllable non-return valves and filters�
if hot or cold water supply fails� • Anti-scalding failsafe: immediate shut-off • 30-year warranty�
• Temperature pre-set at 38°C, can be adjusted if hot or cold water supply fails�
by the installer from 34 - 60°C� • Temperature pre-set at 38°C, can be adjusted
• Brass body� by the installer from 30 - 60°C�
• Filters and non-return valves. • Brass body�
• Recommended flow rate range from 3 - 12 lpm� • Filters and non-return valves.
• Thermal shocks are possible. • Recommended flow rate range from 5 - 33 lpm�
• 30-year warranty� • Thermal shocks are possible.
• Centres: 40mm�
• 30-year warranty�
MW
MW
HW CW
HW CW
75
Ø15
1/2"
140
Ø15
68
65
1/2" 35 1/2"
Ø 15 34 Ø15
Ø15 40 Ø15
732115/732116 733115 200000
PREMIX NANO (from 3 - 12 lpm) PREMIX COMPACT
Nickel-plated body M½", 15mm 732115 M½" 733115
Polished chrome body M½", 15mm 732116 M¾" 733116 Pre-mixer Compact 200000
78 Additional fittings
