Accessories for Commercial Kitchens /

Swivelling spout ON/OFF waste HYGIÉNA waste
Waste with stainless steel valve Waste with concave grid

• Swivelling spout. • Washbasin waste M1¼" with stainless steel • Hygienic washbasin waste M1¼".
• F¾". valve with free flow. • Concave grid (no water retention).
• Chrome-plated brass. • Recommended for all washbasins equipped • Free flow, with no central screw
• Models 966230 & 966380: can be mounted with electronic or time flow mixers/taps (prevents residue build-up).
above or below a wall-mounted mixer. and washbasins with overflow. • Polished chrome-plated brass grid,
• Flow straightener. • Open/close by simply pressing chrome-plated ABS body.
• 30-year warranty. the top of the waste. • Tall version: tightens to a min. 1mm or max.
• 30-year warranty. 45mm; pre-scored waste: (snap-off sections
can be removed for basins with overflow).
3/4" Short version: tightens to a min. 1mm or max.
2mm; special stainless steel washbasins.
• Complies with EN 274-1� 30-year warranty�
135 Ø 61 Ø 63
Ø 42 30 1 - 45 Ø 39 Ø 63
200-290
50 Ø 64
1"1/4 50 1-2 50
966230 1"1/4 1"1/4
Swivelling spout 581000 611 6110
Telescopic L� 200 - 290mm 966230 HYGIÉNA waste
Telescopic L� 300 - 470mm 966380 Tall version 611
Tubular L� 200mm 943200110 ON/OFF waste 581000 Short version 6110

Nylon flexible hose Standard offset connectors Copper tails
For retracting hand sprays M½" M¾" wall-mounted connectors To supply mixers and taps

• Nylon flexible hose L� 1�50m • Chrome-plated connectors • Soft-tempered copper tails�
with counterweight for retracting hand spray for wall-mounted mixers� • Can be installed instead of PEX flexibles�
(see ref. 2597 page 41). • M½" M¾"� • Better conductors than flexibles�
• Conical F½" union and cylindrical M15x1 union� • Supplied in packs of 2� • More effective for thermal shocks�
• 30-year warranty� • Supplied in packs of 2�
• 30-year warranty�
15x1
Ø 64 Ø 70
1/2" 1/2" Pro tip: don’t forget to include non-return valves
3/4"
3/4" on the copper tubes if the PEX flexibles to be replaced
1/2" ADDITIONAL FITTINGS
11 12 have integrated non-return valves�
Contact our Technical team for further information�
50 35-41
60
337
856794.2P 856027.2P
Ø 10 11x1
1,50 m 811611.2P
Standard offset connectors
835T1 L�50mm, C-C 11mm, Ø 64mm 856794.2P
L�60mm, C-C 12mm, Ø 70mm 856027.2P Copper tails
L�60mm, C-C 21mm, Ø 70mm 857027.2P M10 x 1 L� 337mm 811610.2P
Nylon flexible hose L. 1,50m 835T1 L�50mm, C-C 11mm, Ø 70mm 856127.2P M11 x 1 L� 337mm 811611.2P

Additional fittings 71
